Taper Drill Rod

Perfect designs,high quality steel , We provides leading strength and penetration rates for more productivity, excellent straightness and hole clean quality, get max drilling performance to save up fuel cost rate.

Description

Taper Drill Rod

Taper Drill Rod Details

It is suitable for small pneumatic rock drills or hydraulic rock drills for shallow hole drilling operations, and are generally made of H22 and H25 hexagonal hollow drill steel. The tapered drill rod needs to be matched with the taper drill bit for rock drilling, and It is usually used in rock drilling operations in quarries, coal mines, roadbeds, construction and other fields. Conventional taper angles for tapered drill rods are 7°, 11°and 12°.

Technical Parameters
Length (L)		Weight
mm	foot/inch	approx, kg
800	2″	2.8
1220	4′	4.2
1525	5′	5.3
1600	5’3″	5.3
1830	6′	5.9
2000	6’6%	6.6
2435	81	7.7
2435	8′	7.9
3200	10’6°	10.3
3655	H’117/8″	11.7
4000	13’V/21	12.8
4800	159，	15.2
5600	18’4 ‘	17.6
6400	21′	20
7200	23″	22.4
8000	26*3″	24.9

Service

The technical support team may provide remote or on-site support to resolve issues encountered by users during use.
Provide original spare parts to ensure timely replacement of worn or damaged parts to maintain the normal operation of DTH bits.
Timely information reply throughout the day, the first time to solve your problems.
